INPUT DC 12V 24V (8-35V) to Output DC 5V 3A max DC-DC Converter Buck Voltage Regulator USB Car Phone Charger Quick Charge 3.0 Tablet Charging Cable
>Product Name: 12V to 5V step down converter with USB
>Brand: Fulree
>Model:Q1
>Input voltage: DC 12V 24V (8-35V)
>Output voltage: DC 3.6-12V auto adaptive (Quick Charge 2.0/3.0)
>Output current: DC 3.6-6V---3A max; DC 6.2-9V---2A max;DC 9-12V---1.5A max;
>Output Power: 18W max
>Input Cable: open wire 12CM (accepted adding connector or customizing length)
>Output Cable:35CM with type A female USB;
>Product Case Size: L46mm*W27mm*H14mm(not include the cable)
>Product Weight:50g/pc
>Benifits: This 12V to 5V Step Down USB Car Charging Cable provide a solution that can quickly charge almost any mobile phone, tablets, GPS, digital camera, PSP/MP3/MP4 and other USB-devices on most DC 12V 24V motorcyle vehicle.
Specifications:
• Module Properties: non-isolated buck step down converter module
• Rectification: synchronous rectification • Minimum pressure difference: 3V
• Conversion efficiency: 90% • Soft-start time: 500mS • Output ripple: 50mV (MAX) 20M-
bandwidth
• Full load temperature rise: 50°c
• Load regulation: ± 1%
• Voltage regulation: ± 2%
• Dynamic response speed: 5% 200uS • Operating Temperature: Industrial (-40°c to +85°c) ( If ambient temperature exceeds 40°c, lower power use, or to enhance heat dissipation)
Quick Charge:
The solution support Qualcomm Quick Charge QC2.0,QC3.0 and Huawei FCP, that can cover most quick charge protocol in the market.
If your mobile phone without quick charge function, the normal charging solution is compatible,don't worry it.
Feature:
• Overcurrent protection •Overheat protection• Short-circuit protection • Waterproof
